2014 Official 1LE Specs

Wheelbase 112.3
Length 190.4
Height 54.2
Front Track 63.7
Rear Track 63.7
Head Room, Front 37.40
Head Room, Rear 35.30
Shoulder Room, Front 56.90
Shoulder Room, Rear 42.50
Leg Room, Front 42.40
Leg Room, Rear 29.90
Weight 3860 pound SS Coupe Manual Trans
Weight distribution 52/48
Compression ratio 10.7:1 LS3
HP 426 (318) @ 5900 SAE certified ( LS3 )
Torque 420 (569) @ 4600 SAE certified (LS3 )
Displacement 376/6162
Maximum Engine Speed (RPM) 6600 (LS3)

Exhaust - Cast stainless steel (exhaust manifolds), stainless steel with active valves and quad 3.5" bright tips

2014 1LE COUPE TOTAL PRODUCTION

  • Assembly Oshawa, Ontario Canada
  • Total 1LE Performance Package: 2,468
    • Memo: w/1SS Package: 676
    • Memo: w/2SS Package: 1,792

2014 1LE PRODUCTION NUMBERS
COLOR USA Canada Count
Crystal Red (GBE)
92
5
 97
White (GAZ)
533
44
 577
Red Hot (G7C)
309
18
 327
Ashen Gray (GLJ)
220
21
 241
Blue Ray (GXH)
104
16
 120
Yellow (G7D)
128
11
 139
Black (GBA)
627
63
 690
Red Rock (G7P)
136
12
 148
Silver (GAN)
122
7
 129
Totals:   2271 197 2468


2014 COLORS

  • Black
  • Ashen Gray
  • Blue Ray Metallic
  • Red Rock Metallic ( New for 2014 )
  • Bright Yellow ( New for 2014 )
  • Silver Ice Metallic
  • Summit White
  • Red Hot ( New for 2014 )
  • Crystal Red Tintcoat

WHEEL OPTIONS

1LE offers one 20-inch wheel for the 2014 model year and engineered to the highest standards.

Standard 10-spoke wheel is black with a low-gloss clear coat, forged alum and has the CAMARO logo. These wheels are 11 lbs. lighter than the current 2SS model wheels.

EXTERIOR/TRANSMISSION/INTERIOR

Exterior:

  • Forged aluminum wheels ( as listed above )
  • Power Sunroof ( option )
  • Matte Black Hood, front splitter and rear spoiler ( standard )
  • RS package ( option on 1SS & 2SS models )
  • Ground effects package ( optional )
  • Satin nickel fuel door ( optional )
  • Red brembo brake calipers, 4 piston system ( standard )
  • Dual mode exhaust ( optional )
  • Electric power steering ( standard on 2014 SS models )
  • 2014 Production version camaro 1LE will have center hood heat vent with satin black hood wrap
  • Recaro Seating ( optional ) (New for 2014)
  • 2014 Chevy Camaro 1LE, which features a new, more-streamlined front fascia, Hood and heat extractor that also moves air to help create down force. The reworked Rear fascia has all new trunk-lid, Spoiler, Tail lamps and lower Fascia. The 2014 Camaro 1LE not only stands out from its previous model, but hands down is a serious contender for this model year. We truly believe the 1LE will soon have a collectibility standard and will be low in production numbers. This in turn will make the Camaro 1LE a prized vehicle in the years to come.
  • 2014 has some small enhancements to the Camaro's front and rear alter the overall look substantially. Chevy worked on enhancing the car's aerodynamics by reshaping the front end. The upper grille is narrower while the lower grille is larger. But overall length, width and height all remain the same as before.
  • In back, the taillights are the most striking change; they go from a blocky design to one that is razor thin. These lights were the previous car's most talked about attribute because they were mimicked on other Chevy models.

Transmission:

  • Six speed manual is standard
  • No Automatic transmission for Camaro 1LE
  • Tremec TR6060 Six speed Manual SS with 1LE Package
  • First: 2.66
  • Second: 1.78
  • Third: 1.30
  • Fourth: 1.00
  • Fifth: 0.74
  • Sixth: 0.50
  • Reverse: 2.90
  • Final drive ratio: 3.91

Interior:

  • Sueded-microfiber wrapped steering wheel and shift knob - ( standard )
  • Audio system 7" inch diagonal color touch screen display - ( standard )
  • Navigation integration on 7"inch touch screen mylink ( optional )
  • Embroidered center console lid , requires RS package ( optional )
  • Illuminated footwells ( optional )
  • Rear vision package ( standard on 2SS 1LE's )
  • Premium audio system ( standard on 2SS 1LE's )

OTHER DETAILS:

  • Four-pack auxiliary guages
  • 6-way power driver and passenger seats
  • Bluetooth for select phones
  • Boston Acoustics premium nine-speaker system
  • Rear camera display on " 7inch touch screen dash for 2014
  • Rear park assist
  • USB port
  • PDIM (Preferred Device Interface Module)
  • XM Satellite with 3 trial months

Changes to optimize the 1LE for track-day use include:

  • Larger, 27-mm solid front stabilizer bar, and 28-mm solid rear stabilizer bar for awesome body control
  • Higher-capacity rear-axle half shafts to help with increased horsepower levels of traction
  • Strut tower brace for improved steering and response
  • ZL1-inspired 20 x 10-inch front and 20 x 10-inch aluminum wheels
  • 285/35ZR20 Goodyear Eagle Supercar G:2 tires front and rear ( same as the front tires for ZL1 )
  • ZL1 wheel bearings, toe links and rear shock mounts for track performance
  • ZL1 high-capacity fuel pump and additional fuel pickups for fuel delivery during high-load cornering.

1LE Part Numbers:

  • Strut Tower Brace (LT, SS, 1LE) - 22756880
  • Wheel Hubs (ZL1, 1LE) (4) - 25954415
  • Front Coil Spring (SS, 1LE) (2) - 92245257
  • Front Strut (1LE) (passenger side) - 22812984
  • Front Strut (1LE) (driver side) - 22812985
  • Front Sway Bar (1LE) - 22812946
  • Front Sway End Link (SS, ZL1, 1LE) (passenger side) - 22842515
  • Front Sway End Link (SS, ZL1, 1LE) (driver side) - 22842516
  • Rear Shock Mount (ZL1, 1LE) (passenger side upper) - 22836734
  • Rear Shock Mount (ZL1, 1LE) (driver side upper) - 22836727
  • Rear Coil Spring (SS, 1LE) (2) - 92195466
  • Rear Shocks (1LE) (2) - 23115372
  • Rear Sway Bar (ZL1, 1LE) - 22786260
  • Rear Sway Bar Endlink (SS, ZL1, 1LE) (2) - 22761221
  • Rear Lower Control Arm (SS, ZL1, 1LE) (2) - 20942237 (Needed for 2010-2011 car conversion)
  • Rear Toe Link (ZL1, 1LE) (2) - 22845487
  • 3.91 Gears only ( 1LE ) - 22813040
  • Hood (SS 1LE) - 22972003
  • Deflector , Hood Air (SS 1LE) - 23213078
  • Spoiler (SS 1LE RS PKG) - 23436342
  • Tail Lamp (LED RS PKG) - 23209712, 23256982
  • High mount Stop - 23172447
  • Rear Fascia lower without NPP - 22829476
  • Rear Fascia upper with backup sensors - 23164145
  • Tail Lamp Non RS PKG - 23489170, 23489171
  • Rear Fascia lower with dual mode - 22829477
  • Rear Fascia upper no backup sensors - 23164146
  • Front Fascia with RS PKG - 22997721
  • Front Fascia without RS PKG - 22997719
  • Grille Front upper without RS PKG - 22829516
  • Headlamp without RS PKG - 23187850, 23446648
  • Headlamp with RS PKG HID HALO - 23187857, 23187856
  • Emblem Front Grille - 22831295
  • Bracket Front License Plate - 22833651
  • Plate Front Grille EMB BKG with RS PKG - 22829512, 22829506
  • Plate Front Grille EMB BKG without RS PKG - 22829511, 22829505
  • Scoop, Hood Air Black - 22828242
  • Front Fog Lamp - 22830038
  • Front Fog Bezel - LH-22829542--RH-22829543
  • Front Upper Grille Chrome Trim RS PKG - CTR-22829525--RH - 22847642--LH - 22847641
  • Wheels 20x10 Black ( ZL1-1LE ) - 22798741
  • Wheels 20x11 Black ( ZL1-1LE ) - 22798743
  • SS/1LE with 1SS with Black interior,so these are Black "NON" heated seat cover numbers.
  • Bottom drivers side - 23127746
  • Back drivers side - 23127745
  • Bottom passenger side - 23128319
  • Back passenger side - *No part number listed yet*
  • SS/1LE with 2SS with Black heated Recaros
  • Bottom drivers side cover - 23128297 - List is $876.73
  • Back drivers side cover - 23128291 - List is $1,317.85
  • Bottom passenger side cover - 23128315 - List is $876.73
  • Back passenger side cover - 23128308 - List is $1,317.85

2014 1LE VIN DECODER

2 Canada
G General Motors
1 Passenger Car
F Camaro (Fbody )
S S = 1SS 1LE Manual | T= 2SS 1LE Manual | K= SS Auto No 1LE in Auto Trans (Note: 1LEs may either come with a T or an S in the VIN to designate manual transmission)
1 37 - Coupe 2 - Door Notchback
E Restraint System
W Engine Type - LS3/ J= L99 No 1LE's in L99
9 Check Digit ( Could be 1-Thru-9 Digit )
E Model Year E=2014
9 Plant Location - Oshawa #1
1
3
8
4 Vehicle Sequence #
9
5

Black Hood Wrap Replacements

Original Wraps at: 1-866-944-9727

Hood Wrap Care on Camaro 1LE

The 1LE package features a matte black hood graphic manufactured and warranted by 3M. To maintain the appearance of the graphic, hand washing or a touchless car wash is recommended.

Tip: Do NOT polish or wax the graphic. Using polish, wax or any solvent-containing products will discolor the graphic. The hood wrap on this vehicle is not a GM warranty part. Owners are directed to contact their dealer for any warranty claims. The warranty form for this graphic is included in the glove box of the vehicle. Dealers are to arrange an assessment of the claim with 3M.
